Scott Addict Gravel 40

Scott Addict Gravel 40
  • Color: Olivine Green/Blackberry Purple
  • Color: Mineral Grey
  • Color: Python Black
$3,799.99
Color:
Size: Select size
Wheel Size: 700c
Please select options Unavailable

Details

The SCOTT Addict Gravel 40 will get you wherever you’re going, no matter what the trail throws at you. More progressive, more control, and more mounts mean this adventure-ready machine is your ticket to getting out there. Find yourself, get lost.

Key Features
- Addict Gravel HMF Carbon Fork
- Addict Gravel HMF Carbon Frame
- Shimano GRX RX822/610 Disc 12 Speed
- Syncros RP2.0 Disc Wheels
- Schwalbe G-One Bite Tires

Frame SizeXS/49S/52M/54L/56XL/58
Head Tube Angle (degrees) 70 70 71 71 71
Head Tube Length (mm/in) 95.0 / 3.7 122.0 / 4.8 140.0 / 5.5 166.0 / 6.5 187.0 / 7.4
Top Tube Horizontal (mm/in) 518.0 / 20.4 534.5 / 21.0 554.5 / 21.8 578.5 / 22.8 592.5 / 23.3
Standover Height (mm/in) 759.0 / 29.9 786.0 / 30.9 807.0 / 31.8 828.0 / 32.6 847.0 / 33.3
Bottom Bracket Offset (mm/in) -71.0 / -2.8 -71.0 / -2.8 -71.0 / -2.8 -71.0 / -2.8 -71.0 / -2.8
Bottom Bracket Height (mm/in) 283.0 / 11.1 283.0 / 11.1 283.0 / 11.1 283.0 / 11.1 283.0 / 11.1
Wheelbase (mm/in) 1,009.4 / 39.7 1,022.9 / 40.3 1,029.2 / 40.5 1,048.7 / 41.3 1,063.5 / 41.9
BB Center to Top Tube Center (mm/in) 447.0 / 17.6 477.0 / 18.8 498.0 / 19.6 516.0 / 20.3 536.0 / 21.1
BB Center to Top of Seat Tube (mm/in) 477.0 / 18.8 507.0 / 20.0 528.0 / 20.8 546.0 / 21.5 566.0 / 22.3
Seat Tube Angle (degrees) 74.5 74 73.5 73 73
Chainstay Length (mm/in) 425.0 / 16.7 425.0 / 16.7 425.0 / 16.7 425.0 / 16.7 425.0 / 16.7
Reach (mm/in) 374.1 / 14.7 378.4 / 14.9 387.1 / 15.2 398.2 / 15.7 406.1 / 16.0
Stack (mm/in) 519.0 / 20.4 544.4 / 21.4 565.3 / 22.3 589.9 / 23.2 609.7 / 24.0
Stem Length (mm/in) 83.0 / 3.3 93.0 / 3.7 103.0 / 4.1 103.0 / 4.1 113.0 / 4.4
Frame SizeBody Height (cm)Body Height (in)
XSS / XS / S < 165 < 65
XS / S / M 165 - 175 65 - 69
M / L 175 - 185 69 - 73
L / XL / XXL 185 - 195 73 - 77
XL / XXL > 195 > 77

Specs

Frame Addict Gravel HMF Carbon Gravel geometry / Replaceable Derailleur Hanger Internal cable routing Syncros fender kit ready
Fork Addict Gravel HMF Flatmount Disc 1 1/4"-1 1/2" Eccentric Carbon steerer
Wheels Syncros RP2.0 Disc Syncros SL Axle / Removable Lever with Tool
Tires Schwalbe G-One Bite Performance 700x45C
Bottom Bracket Shimano BB-RS500 PB
Crankset Shimano GRX FC-RX610-1 40
Shifters Shimano GRX ST-RX610 / BL-RX610L 12 Speed
Rear Derailleur Shimano GRX RD-RX822 GS 12 Speed
Cassette/Freewheel Shimano CS-M7100-12 10-45
Chain Shimano CN-M6100-12
Brakes Shimano BR-RX410 Hyd. Disc
Rotors Shimano SM-RT70 CL rotor 160/F and 160/R
Handlebars Syncros Creston 2.0 X Alloy 31.8mm
Stem Syncros RR2.0 1 1/4" / four Bolt 31.8mm
Headset Acros AIF-1134
Seatpost Syncros SP-R101-CF
Saddle Syncros Tofino Regular 2.0 Cutout

* Subject to change without notice.

Part Numbers

Option UPC MPN Store SKU
Mineral Grey / X-Small / 700c 07616185210535 4232347241004
Mineral Grey / Small / 700c 07616185210542 4232347241006
Mineral Grey / Medium / 700c 07616185210559 4232347241008
Mineral Grey / Large / 700c 07616185210566 4232347241010
Mineral Grey / X-Large / 700c 07616185210573 4232347241012
Python Black / X-Small / 700c 07616185210658 4232348102004
Python Black / Small / 700c 07616185210665 4232348102006
Python Black / Medium / 700c 07616185210672 4232348102008
Python Black / Large / 700c 07616185210689 4232348102010
Python Black / X-Large / 700c 07616185210696 4232348102012
Olivine Green/Blackberry Purple / X-Small / 700c 07616185210597 4232348094004
Olivine Green/Blackberry Purple / Small / 700c 07616185210603 4232348094006 210000015012
Olivine Green/Blackberry Purple / Medium / 700c 07616185210610 4232348094008 210000015011
Olivine Green/Blackberry Purple / Large / 700c 07616185210627 4232348094010 210000015010
Olivine Green/Blackberry Purple / X-Large / 700c 07616185210634 4232348094012
